INFINITY 180
Brand:
Product Code: 816081
INFINITY 180 is MMA and TIG inverter, electrode welding machine in direct current (DC) with scratch striking.
INFINITY 180
code 816081
MMA and TIG inverter, electrode welding machine in direct current (DC) with scratch striking.
Use with a wide range of electrodes: rutile, basic, stainless steel, cast iron, etc.
Features:
- compact and light
- high welding current stability in spite of mains voltage fluctuations
- arc force, hot start and anti-stick devices
- thermostatic, overvoltage, undervoltage, overcurrent, motorgenerator (+/- 15%) protections.
Complete with MMA welding accessories.
| Characteristic | |
| CODE | 816081 |
| MAINS VOLTAGE | 230 V |
| MAINS FREQUENCY | 50 / 60 Hz |
| CURRENT RANGE | 20 - 160 A |
| D. USABLE ELECTRODES IN DC | 1,6 - 4 mm |
| MAX CURRENT | 160A @ 35 % |
| MAX NO LOAD VOLTAGE | 60 V |
| MAX ABSORBED CURRENT | 120 A |
| MAX ABSORBED POWER | 4,5 kW |
| EFFICIENCY | 90 % |
| POWER FACTOR (cosphi) | 0,7 |
| PROTECTION DEGREE | IP23 |
| DIMENSIONS | 35,5 x 14,5 x 24 cm |
| Weight | 6,145 kg |
