INFINITY 180

Brand:
Product Code: 816081

INFINITY 180 is MMA and TIG inverter, electrode welding machine in direct current (DC) with scratch striking.

INFINITY 180

code 816081

MMA and TIG inverter, electrode welding machine in direct current (DC) with scratch striking.
Use with a wide range of electrodes: rutile, basic, stainless steel, cast iron, etc.
Features:
- compact and light
- high welding current stability in spite of mains voltage fluctuations
- arc force, hot start and anti-stick devices
- thermostatic, overvoltage, undervoltage, overcurrent, motorgenerator (+/- 15%) protections.
Complete with MMA welding accessories.

Characteristic
CODE 816081
MAINS VOLTAGE 230 V
MAINS FREQUENCY 50 / 60 Hz
CURRENT RANGE 20 - 160 A
D. USABLE ELECTRODES IN DC 1,6 - 4 mm
MAX CURRENT 160A @ 35 %
MAX NO LOAD VOLTAGE 60 V
MAX ABSORBED CURRENT 120 A
MAX ABSORBED POWER 4,5 kW
EFFICIENCY 90 %
POWER FACTOR (cosphi) 0,7
PROTECTION DEGREE IP23
DIMENSIONS 35,5 x 14,5 x 24 cm
Weight 6,145 kg
